QINGDAO ATLAPEX INDUSTRY CO.,LTD

SPECIFICATIONS

  • Mixing Capacity

    1.5m³

  • Total Weight

    4500KG

  • Power

    78KW

DESCRIPTIONS

A self-loading concrete mixer is a multi-functional machine that can self-loading all the concrete ingredients, mix, transport, and discharge.

Self loader mixer usually possesses a four-wheel-drive system that gives high traction to help the machine work in very soft clay site conditions.

It has a hydraulic-driven drum that provides high turning that assists in reliable mixing procedure. Once the mix is ready the drum can be lifted for fast and also reliable discharge of concrete.

The self concrete mixer machine has a steel bucket that makes it possible for the operator to load resources to the drum.

The loading and also blending operations, the speed, and direction of the drum are all regulated from the cabin of the vehicle

A self loading transit mixer can be quickly packed in big vehicles and also delivered to any kind of long-distance construction site. This feature makes it suitable for little, slim, and isolated building and construction sites.

1

1- Luxury cab. The luxurious cab, with the sturdy cab frame, the flight level seat, the wide field of vision, the driving is very comfortable, and the anti-rollover seat can meet the space and comfort requirements of the driver.

2

2- Stirring system. Stirring system, national standard ferromanganese thickened tank, large torque reducer, with thick stirring shaft, reinforced stirring teeth, reliable performance and more durable.

3

3- Discharge port. Discharge port The vehicle is equipped with 2 discharge ports as standard, and can also be customized according to user needs. The discharge port is fast, no material jamming, and no material leakage.

4

4- Loading bucket. Loading bucket, cement bucket Equipped with a 0.4 cubic feeding bucket, the national standard manganese steel thickened material, with a discharge bin door, which can accurately control the material ratio, and realize downturning and unloading at any angle without dead ends.

5

5- Reinforced engineering tires. Reinforced engineering tires, wear-resistant, strong off-road, not afraid of complex terrain, safe and reliable.

6

6- Hydraulic system. Hydraulic system, hydraulic pilot operation, the whole vehicle adopts domestic first-line brand hose, hydraulic pump, hydraulic cylinder, hydraulic oil, the service life is more than 5 times higher than that of ordinary brands, and it can achieve 24-hour operation without high temperature.

7

7- Engine. Engine: It is equipped with National III high-pressure common rail engine, Yuchai, Yunnei and Weichai are optional, the average fuel consumption is 25%-30% lower, the power is strong, economical and durable, energy saving and environmental protection.

TECHNICAL PARAMETERS

ModelS1500
Machine size (mm)5100×1900×3100 mm
Wheelbase (mm)2600 mm
Total weight(Kg)4500 kg
Axle number traction type4X4
Tire Size20.5-16
Drive axle1.5T hub reducer
EngineYUNNEI 4102 TURBO supercharged
Power (Kw)76
Gearbox265 integrated
Travel speed(km/h)30 km/h
Max.Gradeability30 °
Minimum turning Ratio4000 mm
Min.Ground Clearance300 mm
Tank diameter1700 mm
Tank deepth750 mm
Mixing capacity (m³)1.5 m³
Bucket capacity (m³)0.4 m³
Reduction ratio1:28
Rotating speed(laps/minute)≥20 laps/minute
Quantity of discharge port2 (customerized)
Height of discharge port900 mm
Turning angle of discharge port±90 °
Water Tank Capacity500 L
Tank driving typeHydraulic
Working efficiency 9CBM/28 Tons /Hours
